HiTec 5585 MH

Details


Availability	5 in stock
Weight	0.33 lbs
SKU	HS-5585MH
Market Price:	$90.95
Our Price:	$69.99

Description

Product Description

Increase your performance not your budget with the high voltage, high torque, digital HS-5585MH. Featuring a high performance coreless motor, heavy-duty metal gears and dual ball bearings, the HS-5585MH is rated for 7.4 volt, 2S LiPo operation (or NEAR the same performance with a Redwing LIFE battery. The HS-5585MH, supplies your airplanes up to 35 percent with outstanding strength and precision.

Get all the muscle you need without straining your wallet! Hitec is proud to introduce our economical, premium digital, high voltage, coreless motor servos, the HS-5585MH

Specifications

Torque:
- 194 oz/in at 6V (14 kg/cm)
- 236 oz/in at 7.4V (17 kg/cm)
Speed:
- .17 sec at 6V
- .14 sec at 7.4V
Voltage: 6V - 7.4V
Weight: 2.10oz (60g)
Size: 1.57 x 0.78 x 1.49 in (39.8 x 19.8 x 37.8 mm)
Motor Type: Standard HV Digital
Bearing Type: 6.0 - 7.4 Volts DC

Advanced Servo Specifications Hitec 5585 MH

Control System: Standard HV Digital
Operating Voltage Range: 6.0 - 7.4 Volts DC
Operating Temperature Range: -4° - 140° Fahrenheit
Idle Current: 4 mA
No Load Running Current (6.0V/7.4V):
Stall Current (6.0V/7.4V): 2100 / 2700 mA
Dead Band Width: 2 µs
Potentiometer Type: 4 Slider 1M Cycle
Connector Wire Length: 11.8 in. / 300 mm.
Connector Wire Gauge: 25 AWG
