Dual Power Switch w/Charge Ports

Description:
The Optical Kill Switch for gas rc planes, allows you to safely and remotely kill your electronic ignition. It is Fiber Optically Coupled to isolate your ignition system from your radio system so there is NO interference



Features:

• Includes a remote mountable bright LED to indicate when the ignition is armed.
• Fiber Optic coupled input/output.
• Li-Po/Li-lon/A123/Ni-Mh/NiCad Input.
• Up to 20 Volt 16 amp MOS-FET(IRF7456) output.
• Low to 3Volt 3amp output.
• Low Voltage Drop-Less than 150mv.
• 100% Surface Mount Technology.
• Heavy Gauge Wires,universal connectors.
• Small and light weight –only 0.3 OZ!(8g)
• Reverse Bettery input protection.
• Shut down the transmitter power or receiver to cut off automatically when kill engine







•
•
•

HV Dual Charging Switch (Futaba/JR Connector)

FUTABA GYC470 All-Purpose Car Gyro































































































































































































Product Description

With 4 times the resolution of its predecessor, the Aurora 9, the Aurora 9X is sure to become a favorite among the most demanding pilots. It is HiTec's first triple protocol radio which allows selection from the G1 and G2 Adaptive Frequency Hopping Spread Spectrum (AFHSS) or Secure Link (SLT) 2.4GHz technologies. It features dual processors for fast low latency response and ultra-smooth 4096 resolution. With more than 30 additional programming enhancements and new dynamically assignable switches, it is sure to thrill sport and professional level airplane and helicopter pilots alike.



Features



• Built in AFHSS 2.4GHZ / SLTTM Module (Single / Bi-Directional Selectable)
• 4096 Resolution
• Improved Latency (Dual Processor 7ms Frame Rate)
• Vibration Mode
• Included Touch Screen Stylus
• Easy-to-Read, Easily Accessible 5.1-inch Wide Backlit LCD Touch Screen (320 x 80 Pixels)
• Customizable Menu
• One-Stop Model Type Setting
• 3 Multi-Tasking Digital Trims
• Fully Assignable Control Switches, Knobs, Sticks and Digital Trims
• Ultra-Smooth Quad Ball Bearing Gimbals
• Full-Size Comfortable Hand Grips (Top Quality Elastomer)
• Selectable 4 Different Control Stick Modes, Plus 2 Additional Manual Modes (Software)
• Easy Gimbal Mode Change and Tension Adjustment (Hardware)
• Power Management System (Adjustable Backlight & Auto Shut-off Time)
• Digital Trim Nano-Adjuster (200 Adjustable Trim Steps)














•
•
•
•
•
•
•
•
•
•
•

Standard Programming

• 9 Assignable Control Channels
• 3-Model Type Programming (ACRO/GLID/HELI)
• 30-Model Memory
• 20 Character Model Naming
• 8 Flight Conditions with 10 Characters
• Fail-Safe
• Channel Function
• EPA
• Dual Rate & EXP*
• Sub-Trim
• Servo Reverse
• Servo Speed (up to 25 sec. in each direction)*
• Servo Monitor (Monitor & Servo Test)
• 8 Programmable Mixes (5x 2-Point, 3x 7-Point Curves)**
• Trainer
• Throttle Lock

* Capable of a Maximum of 24 rates by 8 flight conditions and 3 switch positions
** Capable of a Maximum of 8 Rates by 8 Flight Conditions
