Extreme RRS--16 CH High Power Expander

Welcome to the world’s first Automatic Intelligent Servo Matching System (ISMS)

Intellimatch is the result of 2 years of research and development, is designed to take the worry out of servo matching and gives you the maximum power, smoothest response and increased life from your servos.

If you have built giant scale models before with multi servo control surfaces then I am sure you will be familiar with the process of manually matching the servos. You generally match servos on 2 end points and maybe a center point. That’s a total of only 3 matching points. There is no way 3 points will accurately match your servos. Also, you have to adjust each servo until minimal buzz is heard or you might use an ammeter to minimize current draw. Throw that idea away...

With the Booma RC Intellimatch you say goodbye to traditional methods of servo matching. The Intellimatch system automatically matches servos on 100 points through the servo sweep range. That is 100 points not just the traditional 2 or 3. Intellimatch further adds smoother operation by reading the closest 2 points from the servos current position and then interpolates between the 2 selected points to a resolution of 8192 steps. 8192 step resolution is the highest resolution available today.

The IM14 Intellimatch unit is designed to match 1 set of up to 4 servos. An example IM14 usage might be up to 4 rudder or ailerons servos

Read on for the full list of features

Model Example 1 - 100cc Scale Aero Model:

-2 Aileron Servos per aileron

-1 Elevator Servo per elevator

-2 Rudder servos

Suggested Power Bus Intellimatch Accessories

-2 x IM22 = 1 x IM22 for Ailerons and 1 x IM22 for Elevators

Model Example 2 - 150cc Scale Aero Model:

-3 Aileron Servos per aileron

-2 Elevator Servo per elevator

-3 Rudder servos

Suggested Power Bus Intellimatch Accessories:

-1 x IM22 = 1 x IM22 for Elevators

-2 x IM14 = for Ailerons

-1 x IM14 = for Rudder

Model Example 3 - Large Jet:

-2 Aileron Servos per aileron

-2 Flap Servos

-1 Elevator Servo per elevator

-2 Rudder servos

Suggested Power Bus Intellimatch Accessories:

-1 x IM22 = for right side Ailerons and Flaps

-1 x IM22 = for left side Ailerons and Flaps

-1 x IM22 = for Rudder

Specs:

• 32 bit Processor for the highest speed and resolution in the industry

• Automatic matching of up to 4 servos on a single channel

• 100 matched point across the servo sweep range

• 82 step real time interpolation between the 100 matched points

• PWM resolution of up to 8200 steps

• Dual LED indication for programming feedback

• Recommended battery chemistry - Life (2 cells), LiPo (2 cells), Lion (2 cells), NiCd(5cells),Nimh(5 cells)

• Maximum input voltage 10 volts

• Minimum input voltage 5 volts

• Compatible with all receivers and Power Distribution systems

• Works with Advanced Radio AR1232 and AR824. Also compatible with all other receiver and Power Distribution systems

• Dual fail safe arming with the supplied arming plug

• On board Flash storage - 100 year data retention

• Weight is only 12 grams

• Dimensions 49mm x 23mm (3.5 x 2.5 inches)

BLUE POWER LED FOR SMARTBUS SMOOTHFLITE AND MULTI SWITCH

Booma RC pin flag switch for IntelliReg, Smart-Fly or Gryphon regulator. This pin flag switch Booma RC is an ultra high quality fail safe switch designed as a replacement switch for Smart-Fly systems, Power System, Power Expander, Regulators as well as Gryphon Heli regulators.

Supplied with 1 x switch actuator and 1 x pin flags.

Description:
Make SURE your control surfaces are moving in even amounts in ALL directions.

Quality you can count on
This high quality CNC anodized throw meter, is made to precisely measure your surface deflections. Just clip on the aileron or elevtor (with it's padded light grab clip) and then turn the dial to show zero. Move your surface up or down and record your degree of throw. Match it with your other side, AND the other direction easily, quickly and PRECISELY!

Spot On 1.25" Servo Arm

High Quality 1.25" Aluminum servo arm from Spot-On RC

Spot On Servo Arms are made of high quality 7075-T6 aluminum, one of the highest strength alloys available for this purpose.  They feature an ultra secure double lock design, keeping your servo arm secure and eliminating any slop between the main servo gear and the arm.  Spot On Servo Arms are also sand blasted and anodized for a beautiful appearance.

Spot on offers their servo arms in many sizes, threads and gear output compatibility.  Spot On arms are offered in:
M3, or #4-40 holes, so you can use ball links that are metric or standard Futaba, Hitec or JR compatible gear mesh. Sizes ranging from 1” to 2” for single arms and 2.5” to 4.5” for rudder arms.

Available colors are Black or Silver

Spot On RC Servo Arms are measured from the center hole of the servo to the outermost hole (for example, a 1” arm is exactly 1” from hole center to hole center).  However the larger sizes offer the option of one or two more additional inner holes so you can use them for future projects or fine tune your ratios.

Redwing RC only offers the V2, upgraded version, with stronger aluminum and finer design.  No matter which Spot On RC Servo Arms you choose you will be sure to experience problem free set up and operation with these high quality servo arms.


AR T-Switch (Telemetry Switch)

Booma RC Regulatori-Switch (6 V Regulated Dual Battery Redundancy switch with Fail-Safe Tech)

If you want a switch that offers complete dual battery balancing and redundancy with an ultra-small footprint for your scale model then look no further. The new Booma RC intelligent redundant battery balancing switch is the answer.

This switch works with any single or dual battery system. Works with battery chemistry and voltage range from 2.5v to 28v. It comes with a Pin Flag and Ultra Bright Blue LED which can be mounted discretely on your scale model. The Pin Flag controls the internally mounted switch and battery redundancy circuit. The result - beautiful scale appearance with dual battery redundancy peace of mind.

This new balancing technology offers zero voltage drop battery balancing and redundancy which means it can handle huge loads without generating heat. This also means your receiver and servos get all the power unlike conventional battery balancing which loses precious power as heat.

Package Includes:

• 1 x Pin Flag Switch with mounting hardware.

• 1 x Ultra Bright Blue LED with mounting hardware.

• 1 x Dual Battery Balancing power switch circuit.

• 2 x sets of Input and Output JR connectors.

Specs:

• Ultra low foot print for the best scale looks.

• Works with single or dual battery configuration.

• Works with all battery chemistries. LiFe. LiPo, Lion, NiMh, NiCD. Battery voltage range can be from 2.5volts to 28 volts.

• Capable of handling input voltages up to 28volts.

•  Minimal external footprint - All you see on the outside of your model is a 3mm Pin Flag socket and (if required) an ultra-high bright Blue LED. The Pin Flag controls the internal power switch and dual battery redundancy.

• Full Dual Battery Redundancy - If one battery fails the other battery takes full control.

•  Maximum Battery Power Balancing - In a dual battery system HS1 draws current proportionally from both batteries while moving both batteries to a complete load balance situation. This means you get the maximum capacity out of both batteries all the time.

• 2 x 25 amp independent circuits. HS1 is 2 x 25amp circuits into a high power matching battery redundancy circuit. HS1 actually uses 4 x 50 amp rated FET circuits for battery power matching. We passively rate HS1 at 25amps per circuit.
