Servo Wire 3 to 3 individual

RCGF 35CC SE Stinger Gas Engine

Scorpion SII-65 & SII-5535 series Stand-Off

Overview

The Tomcat G30cc Motor For 30cc gas airplane This is a high-end motor combines ultra-high power and super efficient design to deliver outstanding performance.

Specifications

• Type:......................... TC-G-6432-KV200(G30CC)
• KV(rpms per volt):... 200
• No load current: ....... 2.2 A @10V
• Resistance:................ 0.04 ohms
• Watts:........................ up to 3000
• Continuous Current:... 65A
• Max Burst Current:.... 80A,10seconds
• Cells:......................... 10 S Li-Po
• Recommended Props: 20x12 to 22x11
• Slots,Poles:............... 24,20
• Diameter:.................. 64 mm
• Shaft: Diameter:........ 10 mm
• Weight:...................... 680 g
• Brushless ESC:......... 100A

HV1250

Description:

The MKS HV1220 is a high quality "Coreless" Servo.

The nice thing about coreless servos is that a light weight wire mesh replaces the heavy steel core. By swapping the metal core for something lighter, this servo is able to produce quick acceleration and deceleration, smooth operation, excellent torque, fast response times, and a guarantied quality performance because it operates at low temperatures.

Specs:

• Torque:
  • 307 oz/in at 7.4V (22.1 kg/cm)
  • 319 oz/in at 8.4V (23 kg/cm)

• Speed:
  • .129 sec at 4.8V
  • .115 sec at 6V

• Voltage: 4.8 to 8.4
• Weight: 2.03oz (57.70 g)
• Size: 1.57 x .78 x 1.45 in (40.0 x 20.0 x 37.0 mm)

• Operating Temp - -10~60centigrade
• Working Frequency - 1520μs / 333hz
• Dead Band- 0.0008ms (Default)
• 15 cm connector wire
• CORELESS Motor
• Double Ball Bearings
• FET Driver
• Direct Drive Potentiometer
• Titanium gears
