SCORPION SII-4020-520KV - FOR 60-64" AEROBATIC AIRFRAMES (6S)

Ask a question about this product
Printable version

Share

Options

Our Price:

$209.99
Quantity (2)

Details

Availability 2 in stock
Weight 3.00 lbs
SKU SII-4025-520
Manufacturer Scorpion

Specifications

This Motor is perfect for Aerobatic Airplanes in the 67-68" range running on a 6s battery, or sport planes in the 8-15lb range.

Recommended Setup -
Motor - SII-4025-520kv
ESC - Tribunus II 06-120A SBEC
Battery - 6s 3500-5000mah
Prop - 17x10E , 18x8E

Stator Diameter 40.0 mm (1.575 in)
Stator Thickness 20.0 mm (0.787 in)
No. of Stator Arms 12
Magnet Poles 14
Motor Wind 13 Turn Delta
Motor Wire 22-Strand 0.25mm
Motor Kv 520 RPM / Volt
No-Load Current (Io) @ 10 v 1.22 Amps
Motor Resistance (Rm) 0.020 Ohms
Max Continuous Current 85 Amps
Max Continuous Power 1850 Watts
Weight 288 Grams (10.16 oz)
Outside Diameter 48.9 mm (1.925 in)
Shaft Diameter 5.98 mm (0.235 in)
Body Length 46.15 mm (1.816 in)
Overall Shaft Length 78.40 mm (3.086 in)
Max Lipo Cell 6s
Motor Timing 5deg
Drive Frequency 8kHz

Weight including packaging

672g
