Description:
With this Imax B6AC multi charger, you can charge using a battery at the feild or your ac plug at home! You can charge up to 6 cell batteries. It's capable of charging most types of batteries, LIFE LIPO LION (A123) NICAD NIMH ETC

If you have a splitter you can charge 2/3 cell batteries at once (using an adapter)



Specifications:

• Input Voltage: DC 11-18V / AC in: 100V-240V 50-60Hz
• Circuit power: Max Charge: 50W / Max Discharge: 5W
• Charge Current Range: 0.1-5.0A
• Discharge current range: 0.1-1.0A
• Ni-MH/NiCd cells: 1-15
• Li-ion/Poly cells: 1-6
• Pb battery voltage: 2V-20V
• Weight: 531g
• Dimensions: 134x142x36mm













Features:

• iMax B6AC 1-6 Cells Digital Multifunctional Balance Charger
• 100-240v AC input or 11-18V DC input
• Microprocessor controlled
• Delta-peak sensitivity
• Individual cell balancing
• Li-ion, LiPo and LiFe capable
• Ni-Cd and NiMH capable
• Large range of charge currents
• Store function, allows safe storage current
• Time limit function
• Input voltage monitoring. (Protects car batteries at the field)
• Data storage (Store up to 5 packs in memory)
• Battery break in and cycling.









Package Contents:

• iMax B6AC 1-6 Cells Digital Multifunctional Balance Charger
• 4mm Banana Plug to Male Deans style connector
• A female Deans style connector to a pair of Alligator clips
• A female Deans style connector to a female Futaba style servo connector
• A female Deans style connector female JST style connector
• A female Deans style connector to Glow Plug type connector
• Power Cord
• User Manual







































































Description:

The Pulse CellMeter-8 is the latest version of battery testers - and is now available to our Redwing customers! If you want a new, easy to use, digital battery and capacity tester, your search is over. The Pulse CellMeter-8 can check the overall and individual voltage of 2 through 8 celled, LiPo / LiFe / Li-Ion batteries and 4 through 8 celled, Nicd / NiMH batteries - as well as instantly provide you with your remaining capacity. Did I mention that happens INSTANTLY? We can't make this stuff up.

This nifty little checker does more than that! The cell button allows you to balance your packs as well. So this isn't your typical bettery tester - but a balancer built in.



Features:

• High visibility LCD display screen
• Easy to use Menus
• Full instructions included
• Balance Mode
• Port for balance plug for up to 8 cell Lipo, LiFe, or Li-Ion batteries
• Instant Battery capacity graph
• Can be used as Servo tester to test standard and narrow servo.
• Port for discharge plug of NiMh/NiCd batteries
• Can be used to check the battery voltage of Lithium batteries including Lipo, LiFe, Li-Ion, as well as NiMH and NiCd batteries.
• Measure the voltage of both individual cells and full battery voltage, can also indicate the highest voltage cell, lowest voltage cell and voltage differential between cells

Specification:
Discharge Current: 1A
Balance Current: 1A
Battery Voltage Test Precision: 0.001V
Battery Type: Can test Li-Po/Li-lon/Li-Fe(2-8S),NiCd/NiMH(4-8S) battery
Servo Test Range: 1000-2000us or 500-2500us



Thrust UAV Riot 250R Pro Edition Racing Drone

ManiaX LiPo 2S 5000mAh 7.4V Receiver Battery 15C







DLE Muffler Extensions

Description:

Choose from 5 sizes!

These extensions fit over the exhaust exits on your DLE muffler. Below are some size dimensions and the muffler that each will fit. It is still a good idea to measure the exits on your muffler.

FORMAT: LxW (width is inside diameter)

A: 63x15 mm : DLE 20RA

B: 64x17 mm : DLE 35RA/40

C: 78x20 mm : DLE 55RA

D: 96x25 mm : DLE 55, DLE 111, DLE 120

E: 121x31 mm : DLE 61, DLE 85

*Sold individually- if you have a twin engine, you will need two extensions

*Each Hose extension comes with a metal clamp to tightly secure it to the muffler.































































































































































































































































































Description:
Male Deans to Male XT60 Connector

With this Deans to XT connector you can convert a battery with T-Plug to XT-60 on ESC / charger
The connector has many applications and can be used for charger adapter.

Features:

• Male Deans T style plug to Male XT60
• Durable design
• Heatshrink seal

Standoff (25mm) 100-120CC (Anodized Gas Engine 25m Stand Off Mounting Kit w/6mm Nuts & Bolts- 4pcs)

High Quality 1" Aluminum servo arm from Spot-On RC

Spot On Servo Arms are made of high quality 7075-T6 aluminum, one of the highest strength alloys available for this purpose.  They feature an ultra secure double lock design, keeping your servo arm secure and eliminating any slop between the main servo gear and the arm.  Spot On Servo Arms are also sand blasted and anodized for a beautiful appearance.

Spot on offers their servo arms in many sizes, threads and gear output compatibility.  Spot On arms are offered in:
M3, or #4-40 holes, so you can use ball links that are metric or standard Futaba, Hitec or JR compatible gear mesh. Sizes ranging from 1” to 2” for single arms and 2.5” to 4.5” for rudder arms.

Available colors are Black or Silver

Spot On RC Servo Arms are measured from the center hole of the servo to the outermost hole (for example, a 1” arm is exactly 1” from hole center to hole center).  However the larger sizes offer the option of one or two more additional inner holes so you can use them for future projects or fine tune your ratios.

Redwing RC only offers the V2, upgraded version, with stronger aluminum and finer design.  No matter which Spot On RC Servo Arms you choose you will be sure to experience problem free set up and operation with these high quality servo arms.
