Power HD LF-20 MG

Contact UsCustomer Reviews

Power HD LF-20 MG

Power HD LF-20 MG
Power HD LF-20 MG
Power HD LF-20 MG
Power HD LF-20 MG
Power HD LF-20 MG
Power HD LF-20 MG
Our Price:

$24.99


Quantity (1)

Availability 1 in stock
Weight 0.31 lbs
SKU HD-LF-20
Manufacturer Power HD

The Power HD LF-20 MG is excellent for a 30cc or 50cc plane. This Digital servo has metal housing around the middle which allows for the heat to rapidly dissipate. With double ball bearings you will have smooth movement and powerful torque when you need it. You cant beat the performance of this servo and at such a great price it's a no-brainer.

The Power HD LF-20 servos are a PERFECT Bargain servo with respectable performance. If you are looking for a top notch budget servo that has better centering and resonlution, you may consider the R25/R30 Power HD servos, but for this price you won't find a better servo!

Specs:

  • Torque:
    • 229.1 oz/in at 4.8V (16.5 kg/cm)
    • 277.7 oz/in at 6.6V (20.0 kg/cm)
  • Speed:
    • .18 sec at 4.8V
    • .16 sec at 6.6V
  • Voltage:
  • Weight: 2.12 oz (60g)
  • Size: 1.60 x 0.80 x 1.55 in ( 40.7 x 20.5 x 39.5 mm)

  • Operating Voltage - 4.8 ~ 6.6 DC Volts
  • Operating Temp- -20~60centigrade
  • Working Frequency - 1520μs / 333hz
  • DC Motor
  • Middle Aluminum Casing With Plastic Top and Bottom
  • Double Ball Bearings
  • Copper & Aluminum Gears
  • Wire length- 300cm
: *
: *
: *


Servo Safety Clips

Description:
10 pack of servo safety clips. Made to retain your servo wires to keep them from slipping off during flight.

A must have to to ensure your servo connectors stay securely connected.

Packs of 10:

EX-clip

$4.95

Compression Springs for SmartDesign V3 "Trouble Free" Tail Wheel Assembly

These Aluminum Hub Wheels are made with High Quality Rubber tires that will make landing softly a breeze. Designed to fit 20cc to 170cc

Wheels are sold in pairs.


Wheel Chart

Features:

  • Reusable Aluminum Hub
  • High Quality Rubber Tire



Pricing



  • 3"- 20-30cc: $15.99
  • 3.5"- 50-60cc: $18.99
  • 4"- 100-120cc: $20.51
  • 4.5"- 150-170cc: $25.00





Weight (for two wheels)





  • 20-30cc: 2.6 oz
  • 50-60cc: 2.8 oz
  • 100-120cc:6 oz
  • 150-170cc: 7 oz



GW-KAG114

$5.99

Dolphin 580mm Wingspan EPP Foam Slow Flyer (Indoor/Outdoor)

31.5" EPP 3D Airplane YAK55 Features: • Kit version - Assemble and install your choice of electronics • All hardware accessories included in kit • Durable EPP material with realistic printing resemblance of a shark • Simple to build Specification: Wingspan: 800mm Length: 875mm Flying Weight: 400g Suggested Power System: Motor: 2212 1400KV ESC: 20A Servo: 9g *4 Propeller: SF 8-9inch Radio: more than 4CH BATT: 2S 1200-1500mAh (Not incl.) Different versions supplied as below: E1701=E17 YAK55 KIT+APC SF9047 E1702=E17 YAK55 KIT+Motor(2212 1400KV+3.5mm Banana Male Plug+3.0mm Prop Adapter) E1704=E17 YAK55 KIT+Motor+ESC(20A E-Power+3.5mm Banana Female Plug+XT60 Plug)+Servo(9g*4)

DW-E36-Dolphin

$64.99
