Mini Switch - with Charge Lead

Heavy Duty Switch - with LED and Charge Jack

Description:
Our LiFe Batteries (also known as A123 Batteries) have huge advantages over most other options.

1) LiFe Batteries are lightweight - as light as Lipos
2) LiFes are safer than Lipos (do not combust easily like lipos)
3) LiFe Batteries supply a constant voltage (They stay right near 6volts from start to finish ensuring consistent flights)
4) Run Life batteries to your servos and ignition without regulators (For extra caution some people run a regulator to their ignition still)
5)Life's have a high Charging Capacity. Charge up to 5amps, allowing you to charge them up in MINUTES!

The 2100 or 3000 Mah can be used as a SINGLE battery system for 30cc planes. (we recommend spliting the lead and put 2 JR leads on, to run to the receiver and the other to ignition). You can also run a single 3000 Life Battery on a 50cc Plane.

The 1450mah LiFE Battery is a great option for those that want a separate battery for ignition and receiver (if you are running FM or hesitant to use a single battery system). The 1450mah Life is a great battery for the ignition for either a 30cc or 50cc sized plane

We recommend the following:
On the MXSR (2) 2100mah, or 1 3000mah placed on the mount box or front of the plane. It is a bigger plane and will do well with the extra voltage and weight.
Other 30cc planes - (1) 1450mah for ignition, (1) 2100mah for receiver or for a lighter set up
(1) 2100mah for both (split the wire to 2 leads) OR (2) 1450mah (one for ignition one for receiver).

50cc sized planes (1) 1450mah LiFe battery for ignition and (1) 3000mah LiFe battery for receiver or, for a lighter set up
(1) 1450mah for ignition, and (1) 2100 for receiver OR (1) 3000mah LiFe for both receiver and ignition



WATCH THIS VIDEO: Explains whether to use a regulator or not, 2 batteries or 1 for your plane, Redundancy and more.


Specifications:

• Type: LiFe Battery (same technology as A123)
• Weight:
  • 1450mah - 2.8oz,
  • 2100mah - 4oz,
  • 3100mah Life - 5.5oz
• Size:
  • 1450mah- 15mm x 34mm x 87mm,
  • 2100mah- 12mm x 50mm x 106mm,
  • 3000mah- 130mm x 45mm x 15m
• Voltage: 6.6Volts
• Discharge rate:
  • 20c maximum continuous
  • 40c maximum burst
• 2 cells (2s)
• 14gauge Wire
• Connectors: Two Options!
  • T Connector (T connector that fit a standard Dean)
  • XT-60 Connector. Choose Below
• Also a balancing lead

Be sure to select the XT connector if purchasing for use with our Power Box PRO's. Please select connector type: Deans or XT.






• 1450mah - $15.99
• 2100mah - $25.99
• 3000mah - $39.99


Description:
These Miracle fuel dots are GREAT looking and function just as well. They are made of machined aluminum, and have a neoprene O-ring for a tight fuel proof fit. They include all the hardware you need and work with all standard size tygon tubing.

$3.95 to $5.95

Description:
Our replacement adjustable push rods are as good as any out there at even better prices. Very similar to Hangar 9's Pro-Links, our adjustable push rods offer the ultimate in strength and security with the added bonus of ease of adjustability and ultra-light weight.

Our Pro-Links have a 4-40 right-hand thread on one side and a 4-40 left-hand thread on the other (turnbuckle). A machined hex in the middle (4mm / 5/32") allows you to make very fine length adjustments without removing the linkage from the servo arm or control horn.

They are also very lightweight, a 110mm (approx. 4.5") linkage weighs just 8 grams but has the strength to lift over 500 pounds. Pro-Links are ideal for any other 4-40 molded ball link or control horn and are available in a variety of sizes. We also have a machined-aluminum wrench that's perfect for making adjustments.


Sizes:

Metric		Approx. US Standard
Non Threaded Length	Entire Rod Including Threads	Non Threaded Length	Entire Rod Including Threads
20mm	45mm	0.79"	1.78"
30mm	55mm	1.18"	2.17"
40mm	65mm	1.57"	2.56"
80mm	110mm	3.15"	4.33"
110mm	140mm	4.33"	5.51"

(Sizes are approximate and can vary between rod length and threads as these are meant to be ADJUSTABLE)


SOLD IN PAIRS
