MKS HBL380

RCGF 15CC RE Stinger Gas Engine

Glow size：economy and powerful

New Series Engines with all new design --  Stinger Engines
More powerful , Stronger material , More precision , More shining

Engine SIZE:

 RCGF 15cc (SE)

1. Parameter
2. Type : 2 cycle piston valve type gasoline engine for airplane
3. Displacement (cc) : 15cc (.91 cu in)
4. Bore x Stroke (mm): 1.3 in (32mm)*0.8 in (19.6mm)
5. Carburetor : Walbro
6. Ignition : DC-CDI (Computer Controlled auto advance, electronic ignition system)
7. Power supply: 6-8.4V
8. Maximum Output : 2.4 hp/1.76KW
9. Requires: Gasoline, 2-cycle oil, ignition battery & propeller
10. speed rang : 1500-15000rpm
11. Gasoline-Version : Pre-mixed Fuel, 25-40 (Gasoline):1 (recommended : 30:1) (90% high otcane unleaded gasoline, Import gas into carbon fiber installations valves)
12. Lubrication Oil : 2 cycle engine oil
13. Propeller : 15*6 9000 rpm; 13*6 11000rpm (Standard Two leafs prop)
14. recommended props :13 x 6, 14 x6,13X8,15X8,15X6
15. recommended Airplane: 60 size plane,50 size plane,40 size plane
16. Cooling System : Air Cooled
17. RCGF engine package Includes: electronic CDI ignition, muffler, spark plug, gaskets, bolts, throttle arm extension & manual.

Weight

1. Engine: 1.31 lb (594 g)
   Muffler: 1.8 oz (51 g)
   Ignition Module: 4.4 oz (125 g)
   Total: Weight: 1.69 lb (770 g)

Technical Data

1. Technical Data:
2. Ignition Battery: 6-8.4 NiCd or NiMH, 6.6V LiFe or 2S LiPo pack
3. Gasoline/Oil Mix: 30:1
4. Replacement Spark Plug: M8 1/4-32 or equivalent
5. Idle Speed: 1800 rpm/min
6. Static Thrust:
7. 10.2 lb (4.6 kg) @ 328 ft (100 m) altitude
8. 9.1 lb (4.1 kg) @ 5,900 ft (1800 m) altitude

50cc EDGE 540 (88")

For anyone who loves their 30cc plane but is looking to upgrade, Redwing RC's new 50cc EXTRA 330 is the perfect bigger-scale model to impress other RC enthusiasts. Available in red and blue, the EXTRA 330 is sure to go the EXTRA mile in performance and quality.

Equipped with the same great features as our other 50cc planes, you can't beat the price of these new stylish, quality built models.

Don't wait! Purchase to reserve one below and be the first to show off this sexy new style!

Product Manual


Specifications:*(More Coming Soon)*

• Wing span: 2260mm / 88.97"
• Wing area: 1480 sq. inches
• All up flying weight: 16.4 lbs
• Length: 2065mm / 84.3"
• Cowl
  • Inside diameter: 10.5" (266.7mm)
  • Inside height: 8.75" (222.25mm)








  •
  •
  •
  •
  •
• Engine: DLE 55, DLE 55RA
• Radio: 6 channel recommended (4ch possible)
• Recommended Spinner Size:
• Recommended CG: 6.75” to 7.25” from the LE at the root of the wing
• Recommended Prop Size:
• Recommended Throws:
  • Low Rates Settings | High Rate Settings
  • Rudder: |
  • Ailerons: |
  • Elevator: |

Features:

• Removable stab
• Ringed cowl
• Adjustable push rods
• Canister ready
• Carbon fiber landing gear and accessories
• Carbon fiber Rei enforcements:
  • CF stringers in fuse
  • CF stringers in wings
  • CF wing reinforcement tubes
  • CF retention pins in stabs/wings
• Fiberglass stab mounts
• Painted matching spinner (Optional)
• Fast fly and easy build features, such as : Pre-drilled hinges, pre-plumbed fuel tank, and pre-installed rudder cable
• NOW COME WITH SIDE FORCE GENERATORS!

tml', 'popup', 'width=500,height=500'); return false">

Taft-Hobby Turbo Bushmaster STOL 72"(1.8M) Wingspan - PNP 6CH with Flaps and LED Lights (Night Flyer)

$20 Flat Rate shipping lower 48 USA only. Contact us at [email protected] to calculate international shipping cost.

RedwingRC Plug-and-Play aircraft!

The Dynam T28 Trojan is a great plane for both beginners and experienced pilots! Just getting started in the hobby or just want to try something new, this plane is for you. The Trojan T28 is made with EPOFLEX (EPO) foam- a damage resistant foam. This aircraft is painted with the famous US Air force color scheme. All surfaces are constructed out of the EPO foam so it is not easily damaged and easily repaired. The Trojan is very stable and is a blast to fly! This is a Plug-and-Play aircraft so it will arrive about 80% complete and included cool scale features such as a clear canopy, retractable landing gears and steerable nose landing-gear .

Build time is around 60 min from box to air.

Expect flight time to be from 6-10 minutes per battery.

Key Features:

• Powerful BM3715 - 890KV outrunner brushless power system
• 30A Brushless ESC
• Retractable landing gears
• Durable and lightweight EPO construction with many surface details
• Detailed Body Structure
• Suitable for both, beginner thru experienced Pilots
• Easy to build
• Scale 3 blade prop

Specifications:
