Tomcat G46 Brushless Motor

Contact UsCustomer Reviews

Tomcat G46 Brushless Motor

Our Price:

$84.99


ESC Combo
Quantity (1)

Availability 1 in stock
Weight 2.00 lbs
SKU TC-G46
Manufacturer Tomcat



Overview

The Tomcat G46 Brushless motor. This is a high-end motor combines ultra-high power and super efficient design to deliver outstanding performance.

Specifications

  • Type: TC-G-5020-KV680 (G46)
  • KV (rpms per volt): 680
  • No load current:  2.8A @10V
  • Resistance: 0.037 ohms
  • Watts: up to 900
  • Continuous Current: 42A
  • Max Burst Current: 58A, 10seconds
  • Cells: 4–5 S Li-Po
  • Recommended Props: 12x8 to 14x10
  • Slots, Poles: 12, 14
  • Diameter:  50 mm
  • Shaft Diamete: 6.0 mm
  • Weight: 310 g
  • Brushless ESC: 60A



: *
: *
: *


Crimper

Description:

Crimper

Use this heavy duty crimper to crimp pin/socket onto your wires. Easy to use and comes with step by step instructions.

Also works as a wire cutter. (see image)



ACC175

$17.99

SCORPION COMMANDER 15V 35A ESC SBEC (V3)

SCORPION COMMANDER 15V 35A ESC SBEC (V3)

ESC-0007

$49.99

Spot On Exhaust Extension

Exhaust Extension

High Quality 1" Aluminum servo arm from Spot-On RC

Spot On Servo Arms are made of high quality 7075-T6 aluminum, one of the highest strength alloys available for this purpose.  They feature an ultra secure double lock design, keeping your servo arm secure and eliminating any slop between the main servo gear and the arm.  Spot On Servo Arms are also sand blasted and anodized for a beautiful appearance.

Spot on offers their servo arms in many sizes, threads and gear output compatibility.  Spot On arms are offered in:
M3, or #4-40 holes, so you can use ball links that are metric or standard Futaba, Hitec or JR compatible gear mesh. Sizes ranging from 1” to 2” for single arms and 2.5” to 4.5” for rudder arms.

Available colors are Black or Silver

Spot On RC Servo Arms are measured from the center hole of the servo to the outermost hole (for example, a 1” arm is exactly 1” from hole center to hole center).  However the larger sizes offer the option of one or two more additional inner holes so you can use them for future projects or fine tune your ratios.

Redwing RC only offers the V2, upgraded version, with stronger aluminum and finer design.  No matter which Spot On RC Servo Arms you choose you will be sure to experience problem free set up and operation with these high quality servo arms.




SPO-TRA-038

$22.99
