Gloster Meteor F8 Twin 70mm EDF Jet V2 6S 12-Blade with Split Flaps

Ask a question about this product

Printable version

Options

Market Price: $499.99

Our Price:

$399.99

You Save

20%

Quantity (1)

Details


Availability	1 in stock
Weight	5.00 lbs
SKU	DY8974V2

RedwingRC Plug-and-Play aircraft!

The Gloster Meteor was the first British jet fighter and the Allies' only jet aircraft to achieve combat operations during the Second World War. The Dynam Gloster Meteor F8 V2 is an exceptional RC airplane that will provide an exhilarating flying experience. With a wingspan of 1270mm (50") and a length of 1510mm (59"), this EDF Jet is the perfect size for outdoor flying.

The Dynam Gloster Meteor F8 V2 is constructed using high-quality EPO foam, which makes it both durable and lightweight. Additionally, the plane is powered by a twin 70mm 12-blade EDF unit with Skylord 80A ESCs and TomCat TC-2860A-2200KV inrunner brushless motors, which provides tremendous thrust and power for impressive flight performance.

This Gloster Meteor F8 V2 RC EDF Jet is designed with a stunning red and silver exterior, complete with authentic decals and markings. The cockpit is also beautifully detailed, with a clear canopy providing a great view of the pilot figure.

Detachable wing and fuselage make transporting the Dynam Gloster Meteor F8 V2 a breeze. The scale split flap design improves the lift coefficient of the plane. High-strength retractable landing gear provides better durability during landings and takeoffs. Enough battery space that pilots can fit a higher capacity battery and flight control system such as the iStone stabilizer or a Detrum SR86A sport receiver.

Features:

Durable and lightweight EPO construction
Aileron, rudder, and elevator controls
Dual TomCat TC-2860A-2200KV inrunner brushless motor
70mm 12-blade double EDF design with TomCat Skylord-80A ESC
Scale split flap
9-gram metal servos
Retractable landing gear
Comes with a decal set
Suitable for beginners, intermediate or experienced pilots

Specifications

Wingspan: 1270mm (50in)
Overall Length: 1510mm (59.44in)
Flying Weight: 2690g (94.8oz)
Wing Loading: 66.4g/dm²
CG (Center of Gravity): 125-130mm from the leading edge of the wing at the root
Power System: 2x TomCat TC-2860A-2200KV inrunner brushless motor - (pre-installed)
Electronic Speed Control: TomCat Skylord-80A ESC - (pre-installed)
EDF: 2x 12-blade, 70mm
Servo: 7x 9g metal servos - (pre-installed)
Landing Gear: E-Retract (Retractable) - (pre-installed)
Aileron: Yes
Elevator: Yes
Rudder: Yes
Flaps: Yes
Approx. Flying Time: 5 minutes

What is Required:

Required Transmitter: 8-Channel or above
Required Receiver: 6CH or above
Required Battery: 6S 22.2V 4500mAh Li-Po 30C w/ EC5 Connector

$20 Flat Rate shipping lower 48 USA only. Contact us at [email protected] to calculate international shipping cost.

DLE 35RA Engine

dle35RA

DLE-35 RA

$399.00 399.00

DLE 55cc Engine

+ Free Shipping (Continental US only!) If international customer, please contact us at [email protected] for shipping quote. You will be charged separately for shipping.

Description:
The DLE 55 is a tried and true engine in the 50cc class size. It is the best bang for the buck, and offers great reliability, power and weight ratio. Comes with all high quality components, includes all hardware (standoffs, ignition, muffler, spark plug, etc). The DLE 55cc is a perfect choice for our 50cc class airframes

Download DLE 55cc Mounting Template
Download DLE 55cc Manual

Specifications:

Displacement: 55.6 cc (3.392 cu in)Manifold: 4-petal, V-type, reed-valve, bottom induction
Bore: 1.77 in (45 mm)
Stroke: 1.38 X in (35 mm)
Weight: 3.6 lb (1.65 g)
RPM Range: 1,350-8,500
Output: 5.5 hp @ 7,500 rpm
Requires: unleaded gasoline, oil, ignition battery & propeller
Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
Suggested Propellers: 23x8, 24x8
Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
Compression Ratio: 7.6:1
Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
Weights (Individual): Engine: 47.6 oz (1,350 g); Exhaust: 3.5 oz (100 g); Ignition: 4.2 oz (120 g)
Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d

Features:

Two crankshaft bearings-simple design for lighter weight
Aluminum alloy crankcase
Four petal V-type reed valve bottom induction system
Walbro carburetor
Fully automatic electronic ignition
Two year limited warranty through Hobby Services beginning at date of purchase
INCLUDES: Engine, spark plug, standoffs, ignition, muffler, instruction manual

DLE-55

$429.00 429.00

SmartDesign V3 "Trouble Free" Tail Wheel Assembly

Description:

This tail wheel assembly is extremely efficient and reliable. With fewer parts, there is less to worry about and the solid construction makes it the go-to choice for pilots at any skill level. The new V2 design incorporates ball bearings for smooth motion, ball-joint to rudder steering connection, wider CF mounting plate, and slightly larger wheels that the v1. "Trouble Free" means just that... no more worrying about screws falling out or loss of control. Make the switch today by installing the SmartDesign Tail Wheel!!!

CNC Aluminum & C.F. Tail Wheel Assembly for 20cc to 220cc

Features:
