Description:
The DLE 55 is a tried and true engine in the 50cc class size. It is the best bang for the buck, and offers great reliability, power and weight ratio. Comes with all high quality components, includes all hardware (standoffs, ignition, muffler, spark plug, etc). The DLE 55cc is a perfect choice for our 50cc class airframes
Download DLE 55cc Mounting Template
Download DLE 55cc Manual
Specifications: - Displacement: 55.6 cc (3.392 cu in)Manifold: 4-petal, V-type, reed-valve, bottom induction
- Bore: 1.77 in (45 mm)
- Stroke: 1.38 X in (35 mm)
- Weight: 3.6 lb (1.65 g)
- RPM Range: 1,350-8,500
- Output: 5.5 hp @ 7,500 rpm
- Requires: unleaded gasoline, oil, ignition battery & propeller
- Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
- Suggested Propellers: 23x8, 24x8
- Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
- Compression Ratio: 7.6:1
- Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
- Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
- Weights (Individual): Engine: 47.6 oz (1,350 g); Exhaust: 3.5 oz (100 g); Ignition: 4.2 oz (120 g)
- Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d
Features: - Two crankshaft bearings-simple design for lighter weight
- Aluminum alloy crankcase
- Four petal V-type reed valve bottom induction system
- Walbro carburetor
- Fully automatic electronic ignition
- Two year limited warranty through Hobby Services beginning at date of purchase
- INCLUDES: Engine, spark plug, standoffs, ignition, muffler, instruction manual
|
