12V Smart Servo, USB Programmable, Waterproof, Mega Torque 60KG (832.2 Oz) Magnetic Sensored, Brushless

Redwing RC is proud to partner with AGFRC and bring you the latest in servo technology! Introducing the SA86BVMW 3S Lipo Compatible 60KG Super Torque Programmable Magnetic Encoder Waterproof Brushless Universal Digital Extended Servo.

As 2s lipo application can no longer meet RC user requirements/usage, this 12V Series Smart Servo was specially designed for higher voltage applications, such as R/C Crawlers/Trucks, Airplanes, Boats, Robots and Industrial/Medical applications. The highlight of this smart servo is the ability to upgrade the firmware via USB programmer to meet different usage as requirements.

Features:

• Simplify- 3S Lipo high voltage application, able to connect with battery directly
• Smooth- Three ball bearings for more power and smoother operation
• Powerful- Extra strong steel patented gears and upgraded robust structure
• Reliable- High quality brushless motor for longer servo life
• Waterproof- Highly accurate magnetic position sensor, allows use in humid or wet conditions
• Precision- High precision CNC aluminum machined housing
• Programmable- Unique USB programming ability, allows users to change the firmware for different usage

Specifications:

• Item Name: SA86BVMW
• Operating Voltage: 10-13 V
• Operating speed: 0.140sec/60° @ 11.1V
• Operating speed: 0.125sec/60° @ 12.0V
• Operating speed: 0.120sec/60° @ 12.6V
• Stall Torque: 48 kg-cm (667 oz-in) @ 11.1V
• Stall Torque: 57 kg-cm (792 oz-in) @ 12.0V
• Stall Torque: 60 kg-cm (834 oz-in) @ 12.6V
• Gear: Steel
• Motor: BLS
• Size: 40*20*41.5mm (1.57 x 0.78 x 1.63 in)
• Weight: 88.5g
• Connector Wire: TYU 300mm / 22AWG
