BIGAOLE BGL-3G-A V2 3-AXIS GYRO SYSTEM

BIGAOLE BGL-3G-A V2 3-AXIS GYRO SYSTEM

The 3G-A stabilizer is a small lighweight, high performance, 3-Axis gyro. The version 2 model allows the option of independent aileron control, so you can have the benefits of a gyro yet retain flaperon, spoileron and or differential functions. Conversely you can still use a single channel to operate both ailerons making this gyro rather versatile. The V2 has also been enclosed in a robust aluminum housing for added protection.

The 3G-A V2 supports 3 types of planes--Standard Wing, Flying Wing and V-Tail. With the latest MEMS technology the 3G-A V2 provides excellent stability, flexibility, and reliability. Whether you are looking for sharp predictability from a 3D-plane or want to have the ability to fly smoothly in the wind, this gyro is a rock solid performer!

 Features:

• Easily switch between 3 modes: Gyro Off, Normal Flight and AVCS
• Great 3D flight performance without compromising stability
• Easy to setup using independent gain adjustments for aileron, elevator and rudder
• Supports single/double Aileron
• Compact light design in robust case

Specifications:

• Dimensions: 36mm x 28mm x 6mm
• Weight: 15g
• Operating voltage: DC 3.5V - 9V
• Operating current: 20ma
• Maximal angular velocity: 800 degrees/sec.
• Servo compatibility: 1.52ms analog servo, 1.52ms digital servo
• Radio compatibility：PPM, PCM & 2.4G
• Operating Temperature: -15℃ - 65℃
