HiTec DB778WP, Ultra-Torque, Brushless, Low Profile, HV Waterproof Servo 20.4kg/283.6oz [email protected]

Contact UsCustomer Reviews

HiTec DB778WP, Ultra-Torque, Brushless, Low Profile, HV Waterproof Servo 20.4kg/283.6oz [email protected]

Our Price:

$139.99


Quantity (15)

Availability 15 in stock
Weight 0.38 lbs
SKU HRC36788S
Manufacturer Hitec

The Hitec DB778WP 32-Bit MCU Low Profile Ultra Torque Waterproof Servo is a high-performance, low profile DB778WP. Manufactured with exclusive “hitecnology” industrial servo innovation, the DB778WP’s design and premium-quality construction was built for demanding commercial applications, yet its superior torque also makes it the perfect hobby servo for 1/10th 2WD & 4WD off-road buggies and touring cars. Engineered with an ultra-efficient brushless motor, high-resolution digital circuit, hardened steel gears and an all-aluminum, IP-67 rated waterproof case, the DB778WP excels when pushed to the limits on ultra-high bite carpet or clay tracks. Take on the competition and drive hard, knowing you are backed by Hitec’s 2-year warranty which affords you the added protection you deserve! Invest in the best with Hitec!

Features:

  • Voltage Range is 3.7V - 8.4V
  • Ultra-Efficient Brushless Motor
  • Hardened Steel Gears
  • All Aluminum Case
  • IP-67 Waterproof Rated
  • High Response, High Resolution Circuitry
  • 32-Bit MCU Technology / 4096 Resolution
  • Smart Sense Technology for Servo Analytics
  • Full Programmability with DPC11 or HFP-30 (sold separately)
  • H25T Industry Standard Output Spline

Specifications:

  • Operating Voltage Range (Volts DC): 3.7V ~ 8.4V
  • Speed (Second @ 60°): 0.08 @ 8.4V
  • Maximum Torque Range: 283.56 oz. / in. @ 8.4V (20.41 kg.cm @ 8.4V)
  • Current Draw at Idle: 28mA @ 7.4V
  • No Load Operating Current Draw: 600mA @ 7.4V
  • Stall Current Draw: 5,500mA @ 7.4V
  • Dead Band Width: 1usec
  • Dimensions: 41.0 x 21.0 x 26.5mm
  • Weight: 68.0g
  • Circuit Type: 32bit Programable Digital
  • Motor Type: Brushless
  • Gear Material: 5 Steel Gears
  • Output Shaft (type / Ømm): H25T
  • Case Material:  Aluminum
  • Dust / Water Resistance: IP-67 Rated
  • Connector Gauge (AWG) / Strand Count: 20AWG


Limited Warranty:
Hitec Servo Warranty: Each Hitec servo is backed by a limited two-year warranty from the date of purchase. Hitec RCD USA, INC. shall REPAIR OR REPLACE, at Hitec RCD, INC., defective equipment covered by this warranty, otherwise the purchaser and/or consumer is responsible for any charges for the repair or replacement of the product.

: *
: *
: *
