PhoenixS 4 Channel 1600mm (63") Sport Glider (PNP) with ABS Plastic Fuse

Ask a question about this product

Printable version

Options

Market Price: $189.99

Our Price:

$159.99

You Save

16%

Radio Combo

Charger Combo

Battery Combo

Extra Prop/Spinner

Quantity (3)

Notify me when back in stock

Details


Availability	3 in stock
Weight	5.00 lbs
SKU	PhoenixS-EXA74207P

The Phoenix S is a quick and easy to assemble 4ch sport electric powered glider that's perfect for general and aerobatic flying. The EPO wings are fitted with carbon spars for strength and each of the large ailerons is reinforced with carbon to eliminate any chance of distortion or twisting. The wings are attached to the fuselage using the Volantex fast connect clip system, after flying, simply squeeze the clips to release the wings.

The lightweight, streamlined fuselage is blow-molded from a tough, rugged, and flexible plastic with plywood formers that will take a lot of punishment, it will bend and flex before breaking. The EPO horizontal stabilizer and elevator are also reinforced with carbon to improve the strength and stop flutter when flying at high speeds. No glue is required when assembling, the vertical and horizontal stabilizer are simply screwed to the rear of the fuselage.

This is the PNF version which is supplied with a pre-installed 2212-1400KV brushless motor, pre-installed 30A BEC brushless ESC, and 4 pre-installed 9g servos. Also supplied is a complete hardware pack which includes a 12x6 folding propeller, propeller adaptor with spinner, horns, push-rods, and screws. All the control surfaces are pre-hinged using strong plastic hinges to reinforce the foam hinge. The Phoenix S is a strong, rugged, electric-powered glider that is stable yet able to perform nice, smooth aerobatics and is perfect for general sports flying.

Features:

A perfect sport and aerobatic electric glider
Tough, rugged, blow-molded fuselage
Carbon reinforcement for strength
Wings and tail are made from tough EPO
Fast connect/disconnect clips for holding the wings to the fuselage
Strong plastic hinges to reinforce the foam hinge
Plug and fly, complete with pre-installed motor, ESC, and servos

Specs:

Wingspan: 63" (1600mm)
Length: 45.7" (1160mm)
Flying Weight: 1.8 lbs (798g)
Motor: BL2212/1400KV brushless motor with folding prop
ESC: Easy-Plug 30A brushless ESC
Servo: 9g x 4 (See all RedwingRC Servos)

PNP version Requires:
4 Channel or more Transmitter and Receiver
7.4V 2S-1500mAh XT60 Li-Po Battery (see all RedwingRC batteries/chargers)
Battery Charger:see combo pricing

Product Manual: English

$20 Flat Shipping US only--contact us at [email protected] to calculate international shipping cost

XQ 4013 digital 6v

Description:
The XQ 4013 servo is the best option out there for 30cc sized 3d planes. Perfect combination of speed and torque and a price point that make the other servo companies jealous.

The XQ 4013 has superior reliability to other servos. They have a core less digital motor, for precise strong movement. The XQ 4013 has all titanium gears, heat sink to reduce overheating, waterproof housing, and great torque and speed.

The XQ 4013 is perfect for a 30CC 3D plane for ALL surfaces. They can be used reliably in a 50cc plane also on all surfaces.

Specifications:

Torque:
- 166.7 oz/in at 4.8V (12.0 kg/cm)
- 197.2 oz/in at 6V (12.8 kg/cm)
Speed:
- .13 sec at 4.8V
- .11 sec at 6V
Voltage: 4.8V - 6V
Weight: 2 oz (59g)
Size: 40x20x39mm
Gear Style: Futaba Arms
Modulation: Coreless Digital
Gear Type: Titanium
Weight: 2oz (59g)
Size: 40x20x39mm

Watch this video of the XQ 4013 beating the Hitec 7985mg

Features:

Titanium Gears
Waterproof
Coreless
Digital
High Torque/High Speed
Smooth resolution

Don't forget to buy some circle servo arms to fit your carbon fiber arms you got in your kit!

X-4013

$42.50 42.50

DLE 55cc Engine

+ Free Shipping (Continental US only!) If international customer, please contact us at [email protected] for shipping quote. You will be charged separately for shipping.

Description:
The DLE 55 is a tried and true engine in the 50cc class size. It is the best bang for the buck, and offers great reliability, power and weight ratio. Comes with all high quality components, includes all hardware (standoffs, ignition, muffler, spark plug, etc). The DLE 55cc is a perfect choice for our 50cc class airframes

Download DLE 55cc Mounting Template
Download DLE 55cc Manual

Specifications:

Displacement: 55.6 cc (3.392 cu in)Manifold: 4-petal, V-type, reed-valve, bottom induction
Bore: 1.77 in (45 mm)
Stroke: 1.38 X in (35 mm)
Weight: 3.6 lb (1.65 g)
RPM Range: 1,350-8,500
Output: 5.5 hp @ 7,500 rpm
Requires: unleaded gasoline, oil, ignition battery & propeller
Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
Suggested Propellers: 23x8, 24x8
Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
Compression Ratio: 7.6:1
Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
Weights (Individual): Engine: 47.6 oz (1,350 g); Exhaust: 3.5 oz (100 g); Ignition: 4.2 oz (120 g)
Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d
