Muffler Extensions, Exhaust Tubes (Fits DLE and other engines)

Contact UsCustomer Reviews

Muffler Extensions, Exhaust Tubes (Fits DLE and other engines)

DLE Muffler Extensions
Our Price:

$6.99


Size
Tube Clamp
Quantity (13)

Availability 13 in stock
Weight 0.10 lbs
SKU DLParts-20

Muffler Extensions
Choose from 6 sizes!

These extensions fit over the exhaust exits on your muffler. Below are the size dimensions and the muffler that each should fit (new versions have different exhuast diameters). It is a good idea to measure the exits on your muffler and select the correct one based on your size.

FORMAT: LxW (width is outside diameter) ID=inside diamerer

A: 63x15mm ID:14mm:(DLE 20RA)

B: 64x18mm ID:17mm:(DLE 35RA/40)

C: 78x22mm ID:20mm :(DLE 30, DLE 55RA)

D: 96x27mm ID:25mm:(DLE 55, DLE 61 (old), DLE 111, DLE 120 (old))

E: 116x30mm ID:27.5mm (DLE 61/120 (new), DLE 85, DLE 170 (old), DLE 222)

F. 116x37mm ID 35mm (DLE 170 (new),

*Sold individually- if you have a twin engine, you will need two extensions

*metal clamp sold separately

: *
: *
: *


LiFe Batteries 2S

Description:
Our LiFe Batteries (also known as A123 Batteries) have huge advantages over most other options.

1) LiFe Batteries are lightweight - as light as Lipos
2) LiFes are safer than Lipos (do not combust easily like lipos)
3) LiFe Batteries supply a constant voltage (They stay right near 6volts from start to finish ensuring consistent flights)
4) Run Life batteries to your servos and ignition without regulators (For extra caution some people run a regulator to their ignition still)
5)Life's have a high Charging Capacity. Charge up to 5amps, allowing you to charge them up in MINUTES!

The 2100 or 3000 Mah can be used as a SINGLE battery system for 30cc planes. (we recommend spliting the lead and put 2 JR leads on, to run to the receiver and the other to ignition). You can also run a single 3000 Life Battery on a 50cc Plane.

The 1450mah LiFE Battery is a great option for those that want a separate battery for ignition and receiver (if you are running FM or hesitant to use a single battery system). The 1450mah Life is a great battery for the ignition for either a 30cc or 50cc sized plane

We recommend the following:
On the MXSR (2) 2100mah, or 1 3000mah placed on the mount box or front of the plane. It is a bigger plane and will do well with the extra voltage and weight.
Other 30cc planes - (1) 1450mah for ignition, (1) 2100mah for receiver or for a lighter set up
(1) 2100mah for both (split the wire to 2 leads) OR (2) 1450mah (one for ignition one for receiver).

50cc sized planes (1) 1450mah LiFe battery for ignition and (1) 3000mah LiFe battery for receiver or, for a lighter set up
(1) 1450mah for ignition, and (1) 2100 for receiver OR (1) 3000mah LiFe for both receiver and ignition



WATCH THIS VIDEO: Explains whether to use a regulator or not, 2 batteries or 1 for your plane, Redundancy and more.


Specifications:

  • Type: LiFe Battery (same technology as A123)
  • Weight:
    • 1450mah - 2.8oz,
    • 2100mah - 4oz,
    • 3100mah Life - 5.5oz
  • Size:
    • 1450mah- 15mm x 34mm x 87mm,
    • 2100mah- 12mm x 50mm x 106mm,
    • 3000mah- 130mm x 45mm x 15m
  • Voltage: 6.6Volts
  • Discharge rate:
    • 20c maximum continuous
    • 40c maximum burst
  • 2 cells (2s)
  • 14gauge Wire
  • Connectors: Two Options!
    • T Connector (T connector that fit a standard Dean)
    • XT-60 Connector. Choose Below
  • Also a balancing lead

Be sure to select the XT connector if purchasing for use with our Power Box PRO's. Please select connector type: Deans or XT.






  • 1450mah - $15.99
  • 2100mah - $25.99
  • 3000mah - $39.99


LiFe

$25.99

Colored Fiberglass Control Horn (Horns)

Colored Fiberglass Control Horns

Replacement control horns for 30cc, 50cc and 100cc planes. Made of light strong fiberglass, these fiberglass control horns fit MOST planes using these style of control horns. Each unit includes 2 single horns and a ball link, so you just need to hook up to your pushrod.


SS-HN-color

$3.50

Viton Tubing Fuel Tube 1 Meter 1/8" ID x 1/4" OD x 1/16" Wall For Gas Engine

Viton Fuel Tube/Tubing 1 Meter 1/8" ID x 1/4" OD x 1/16" Wall For Gas Engine
Safe for Gasoline - sized for DLE engines and many others
3mm i.d. - 6mm o.d.
(also known as medium size - fits the DLE 20/30/55/111 and many other)

Sold in 1 meter (3ft) Sections. Please select how many Meters you want

Viton-Fuel Tube

$19.99
