Bob Smith Industries Insta-Set

Description:
Our LiFe Batteries (also known as A123 Batteries) have huge advantages over most other options.

1) LiFe Batteries are lightweight - as light as Lipos
2) LiFes are safer than Lipos (do not combust easily like lipos)
3) LiFe Batteries supply a constant voltage (They stay right near 6volts from start to finish ensuring consistent flights)
4) Run Life batteries to your servos and ignition without regulators (For extra caution some people run a regulator to their ignition still)
5)Life's have a high Charging Capacity. Charge up to 5amps, allowing you to charge them up in MINUTES!

The 2100 or 3000 Mah can be used as a SINGLE battery system for 30cc planes. (we recommend spliting the lead and put 2 JR leads on, to run to the receiver and the other to ignition). You can also run a single 3000 Life Battery on a 50cc Plane.

The 1450mah LiFE Battery is a great option for those that want a separate battery for ignition and receiver (if you are running FM or hesitant to use a single battery system). The 1450mah Life is a great battery for the ignition for either a 30cc or 50cc sized plane

We recommend the following:
On the MXSR (2) 2100mah, or 1 3000mah placed on the mount box or front of the plane. It is a bigger plane and will do well with the extra voltage and weight.
Other 30cc planes - (1) 1450mah for ignition, (1) 2100mah for receiver or for a lighter set up
(1) 2100mah for both (split the wire to 2 leads) OR (2) 1450mah (one for ignition one for receiver).

50cc sized planes (1) 1450mah LiFe battery for ignition and (1) 3000mah LiFe battery for receiver or, for a lighter set up
(1) 1450mah for ignition, and (1) 2100 for receiver OR (1) 3000mah LiFe for both receiver and ignition



WATCH THIS VIDEO: Explains whether to use a regulator or not, 2 batteries or 1 for your plane, Redundancy and more.


Specifications:

• Type: LiFe Battery (same technology as A123)
• Weight:
  • 1450mah - 2.8oz,
  • 2100mah - 4oz,
  • 3100mah Life - 5.5oz
• Size:
  • 1450mah- 15mm x 34mm x 87mm,
  • 2100mah- 12mm x 50mm x 106mm,
  • 3000mah- 130mm x 45mm x 15m
• Voltage: 6.6Volts
• Discharge rate:
  • 20c maximum continuous
  • 40c maximum burst
• 2 cells (2s)
• 14gauge Wire
• Connectors: Two Options!
  • T Connector (T connector that fit a standard Dean)
  • XT-60 Connector. Choose Below
• Also a balancing lead

Be sure to select the XT connector if purchasing for use with our Power Box PRO's. Please select connector type: Deans or XT.


• 1450mah - $15.99
• 2100mah - $25.99
• 3000mah - $39.99


Untitled Document

Description:

Bob Smith Industries CA Glue

Insta-Cure+™ Super Glue, CA

Insta-Cure+™ is a higher viscosity CA for loose fitting joints in which the adhesive must bridge gaps. Normally, the thicker CA is applied to one surface and then the parts are held tightly together for about 5 to 15 seconds. For large surface areas, including those with close fitting joints such as laminations, INSTA-CURE+ ™ should also be used. To prevent premature curing, don’t spread the glue into a thin film. Lay down a serpentine bead with about 1" separations on one surface, then assemble the parts, letting the pressure spread the CA out.

Directions:

Unscrew top from nozzle. For finer applications, use the extender tip. Apply Insta-Cure+™ CA to one side of the parts being joined, then hold them tightly together for 5-15 seconds. For larger bonding areas, apply serpentine beads of the CA with enough spacing to allow for the spreading of the adhesive. Insta-Set™ accelerator can be sprayed to cure the CA that oozes from joints. Full strength is reached in three hours. Wipe the nozzle clean before replacing screw-on top. Refrigerate to extend shelf life. Cured CA is stable from -40 to 220° F. Soak extender tip in acetone for cleaning

Works Best On:

• Balsa Wood
• Soft Wood

Works Good On:

• Hard Wood
• Glass & Metals
• Fiberglass
• Ceramics
• Hard Plastics
• Rubber
• Laminating
• Water-Resistant
• Reinforcing

Avaliable in 2oz and 3/4 Pocket Size.

Pocket CAs feature a new top that has a pin built into the cap that covers the nozzle. This pin seals the bottle so that if it is tipped over, the bottle will not leak. This makes the Pocket CAs ideal for keeping in your tool or field box, just like our IC-Gel. One disadvantage that the new Pocket CA top has is the bluntness of the nozzle. This makes it more difficult to apply small amounts of the CA, especially in tight places. From the feedback we have received, it appears about 25-30% of users prefer the new Pocket CA top, which means that over 70% prefer our standard top for general bonding purposes. Most users are buying both types. Our original top for the workshop, and the Pocket CA for use out in the field. The 3/4 oz. Pocket CAs are available in BSI's Insta-Cure, Insta-Cure+, Maxi-Cure and Super-Gold+. BSI's new extender tip #304 works on the Pocket CA.

Click to Download Safety Data Sheet

1 Meter Carbon Fiber Rod (solid)

Please contact us for information on if your plane is using Ultracote, or TruCote before ordering if you are unsure

Description:
TruCote covering is a high tech polyester covering that is sensative to heat which makes it easy to apply to your plane. It offers high adhesion, fuel proof/waterproof covering for your plane. Easy to apply using a heat gun and/or iron.

• Specs:
• Width: 23.5”
• Temp to adhesion: Approximately 250 degrees F
• Shrinkage begins: Approximately 275 degrees F
• Maximum recommended temp: Approximately 300 degrees F

For instructions on how to apply covering here is a helpful tutorial:

http://www.rc-airplane-advisor.com/heat-shrink-covering.html


Sold in 1 Foot Sections. Please select how many feet you want.

Please put what plane this is for at checkout so that we can match it!
