BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V

Ask a question about this product

Printable version

Options

Our Price:

$199.99

Quantity (10)

Details


Availability	10 in stock
Weight	0.80 lbs
SKU	BBR-BLS-125AWB
Manufacturer	Blue Bird

Special Order! This is a special order item and is subject to manufacturer availability. Please allow a minimum of up to 2 weeks for processing before items are shipped. No cancelations or returns are permitted.

BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V--Blue Bird's most powerful 1/4-1/5 scale Monster Truck/Crawler/Large Boat servo at over 1750oz!!

Water Proof IP67 (Ingress Protection Rating, 6=Dust Tight, 7=Immersion up to 1Mfor 30 min)

Application / Suitable

1/4、1/5th Scale Vehicles, such as Buggy ( Off-Road ), GT ( On-road ), Monster Truck, Rock Crawler & Large Boats, etc.

Specifications

Stall Torque At 6.6V	99.5 kg-cm / 1382.1 oz-in
Stall Torque At 7.4V	111.4 kg-cm / 1547.3 oz-in
Stall Torque At 8.4V	126.5 kg-cm / 1757.1 oz-in
No-load Speed At 6.0V	0.19 sec / 60°
No-load Speed At 7.4V	0.17 sec / 60°
No-load Speed At 8.4V	0.15 sec / 60°
Stall Current At 6.0V	11.7 Amp
Stall Current At 7.4V	13.5 Amp
Stall Current At 8.4V	15.4 Amp

Protection Mechanism

Soft Start Protection	Soft start back to a neutral position.
Over Voltage Protection	Over 9.0V drive the protection mode, and 8.7V return to normal mode.
Low Voltage Protection	Lower than 5.8V, drive the protection mode, and 6.0V return to normal mode.
Locked Rotor Protection	Stall in 3 sec, output torque goes down.
Temperature Protection	Overheat 85 degrees C (185 degrees F), drive the protection mode and down 75 degrees C (167 degrees F) return to normal mode.
Lose Control Protection	When losing the transmitter signal, that servo will immediately be back to the neutral position and locked.

Power Supply

Operating Voltage Range	6.0V ~ 8.7V ( 2S Li-Fe / 2S Li-Poly HV )
Operating Temperature Range	-20°C ~ +60°C ( -4°F ~ +140°F )

Control Specification

Control System	Higher-order Algorithm of【STMicroelectronics】32-bit MCU AD 12-bit Resolution ( 4096 Steps ) Frequency：Up to 400Hz & 1500us or 1520us
Frame Rate (Signal repeat rate)	Under 1ms【Auto-adaptive with Futaba_UR/SR & Sanwa_SXR & KO_HCS Mode】
Dead Band Width	0.002ms ( Default：2us)

Mechanical Specifications

Ball Bearing	Dual, Stronger Ball Bearings with 1 piece of oil seal.【NMB from Japan】
Gear	Stainless Steel Output Gear With All Steel Gears
Motor	High-Efficiency Brushless Motor
Outside Case	Full Aluminum Alloy Case
Horn / Gear Spline	15 Teeth ( Universal Type )
Connected Cable Length	300 mm (11.81 in) [ TYU : Black w/ Gray & JST : Red w/ Black ]
Connected Housing	Universal Connector [ Black ] + JST Connector [ Red ]
Ingress Protection Rating	IP67 means: 6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes

Physical Specifications

Dimension (mm)	65.8 x 30 x 56.5 mm / 2.59 x 1.18 x 2.22 in
Weight (gram)	229.0 ± 1 grams / 8.08 oz W/O Cable
Product Picture / Dimension Sketch

Includes Servo and Aluminum Servo Arm
