BG-0622WP (Airplane or Sail Boat), WATER PROOF, DIGITAL, HV, MEGA FAST BRUSHLESS (22.5kg/312.5oz 0.065sec @ 7.4V)

Contact UsCustomer Reviews
  0
  5. BG-0622WP (Airplane or Sail Boat), WATER PROOF, DIGITAL, HV, MEGA FAST BRUSHLESS (22.5kg/312.5oz 0.065sec @ 7.4V)
Tariff Information update
more offers

BG-0622WP (Airplane or Sail Boat), WATER PROOF, DIGITAL, HV, MEGA FAST BRUSHLESS (22.5kg/312.5oz 0.065sec @ 7.4V)

Ask a question about this product
Printable version

Share

Options

Our Price:

$55.99
Quantity (17)

Details

Availability 17 in stock
Weight 0.51 lbs
SKU BBR-BG-0622WP
Manufacturer Blue Bird

BG-0622WP (Airplane or Sail Boat), WATER PROOF, DIGITAL, HV, MEGA FAST BRUSHLESS (22.5kg/312.5oz 0.065sec @ 7.4V)

Water Proof IP rated: IP=Ingress Protection Rating
6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes

Application
Sail Boats,
1/8, 1/10 Buggy / Truggy, Crawler, Monster. Airplane. Sail Boats (EP / Gas Engine)



Torque At 4.8V 15.8 kg-cm / 219.5 oz-in
Torque At 6.0V 18.4 kg-cm / 255.6 oz-in
Torque At 7.4V 22.5 kg-cm / 312.5 oz-in
Speed At 4.8V 0.096 sec / 60°
Speed At 6.0V 0.078 sec / 60°
Speed At 7.4V 0.065 sec / 60°



Power Supply
Operating Voltage Range 4.5V ~ 8.5V ( 4 ~ 6 Cell Ni-MH or 2S Li-Poly & 2S Li-Fe )



Control Specification
Control System Digital Controller / AD 12-Bits Resolution ( 4096 Steps )
Dead Band Width 0.001ms ( 1us )



Mechanical Specifications
Ball Bearing Dual
Gear All Metal Gears
Motor Premium Brushless Motor ( Made In Taiwan )
Horn / Gear Spline 25 Teeth ( Same as F-Type )



Physical Specifications
Dimension (mm) 40.6 x 20.6 x 39.7 mm / 1.6 x 0.81 x 1.56 in
Weight (gram) 77 ± 1 grams / 2.71 oz
Product Picture / Dimension Sketch ​






: *
: *
: *
