BLS-A930+ HV MINI, DIGITAL, HIGH TORQUE, METAL GEAR, BRUSHLESS (New Generation) 19.8kg/275.0oz, 0.07 @8.4V

Contact UsCustomer Reviews
  0
  5. BLS-A930+ HV MINI, DIGITAL, HIGH TORQUE, METAL GEAR, BRUSHLESS (New Generation) 19.8kg/275.0oz, 0.07 @8.4V
Tariff Information update
more offers

BLS-A930+ HV MINI, DIGITAL, HIGH TORQUE, METAL GEAR, BRUSHLESS (New Generation) 19.8kg/275.0oz, 0.07 @8.4V

Ask a question about this product
Printable version

Share

Options

Market Price: $86.99
Our Price:

$81.99
You Save

6%
Quantity (70)

Details

Availability 70 in stock
Weight 0.51 lbs
SKU BBR-BLS-A930+
Manufacturer Blue Bird

BLS-A930+  HV MINI, DIGITAL, HIGH TORQUE, METAL GEAR, BRUSHLESS

APPLICATION / SUITABLE
Perfect for 3D Airplane and Jets, Heli 500 Class CCPM cyclic and rudder servo use, EP Aircraft & 1/12th EP Car

SPECIFICATIONS

Torque At 6.0V 14.2 kg-cm / 197.2 oz-in
Torque At 7.4V 17.5 kg-cm / 243.1 oz-in
Torque At 8.0V 19.8 kg-cm / 275.0 oz-in
Speed At 6.0V 0.10 sec / 60°
Speed At 7.4V 0.08 sec / 60°
Speed At 8.0V 0.07 sec / 60°
Protection Mechanism
Soft Start Protection Soft start to a neutral position.
Locked Rotor Protection Stall in 5 sec, output torque goes down.
Temperature Protection Overheat 85 degrees C (185 degrees F), drive the protection mode and down 75 degrees C (167 degrees F) return to normal mode.



Power Supply
Operating Voltage Range 4.5V ~ 8.7V ( 2S Li-Fe & HV Li-Poly Compatible )



Control Specification
Control System 32-bits CPU Digital Calculator / AD 12-Bits Resolution ( 4096 Steps )
Frequency：Up to 333Hz & Neutral：1500us or 1520us
Dead Band Width 0.001ms ( 1us )



Mechanical Specifications
Ball Bearing Dual
Gear All Metal Gears
Motor High-Efficiency Brushless Motor
Horn / Gear Spline 25 Teeth



Physical Specifications
Dimension (mm) 35.5 x 15 x 29 mm / 1.4 x 0.59 x 1.14 in
Weight (gram) 35.5 ± 1 grams / 1.25 oz
Product Picture / Dimension Sketch ​






: *
: *
: *
