BMS-136MG 7.8kg/108oz 0.24sec 6.0V (Retractable Landing Gear Servo)

Description:

Specifications:

*More Coming Soon*

• Displacement: 50cc (3.05 cu in)
• Bore and Stroke: 1.6771in x 1.3779in (42.6mm x 35mm)
• Weight: 2.94 lb (1.33 kilos)
• Output: 5 horsepower
• Requires: unleaded gasoline, oil, ignition battery & propeller
• Includes: electronic ignition, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
• Suggested Propellers: 4x8, 23x10, 23x8, 22x12, 22x10, 22x8
• Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.

Features:

• Four petal reed valve, bottom induction
• CNC milled, 7075 luminum alloy crankcase
• Desert Aircraft. auto advance, electronic ignition
• Walbro carburetor
• Most Torque in its class
• Low vibration
• Long rod to stroke ratio
• Aerobatic power curve
• DA engines are designed using the latest tools and techniques, including 3d CAD and stereo lithography
• Two year limited warranty
• INCLUDES: Engine, spark plug, ignition, instruction manual, and post style standoffs.

*Takes 4-5 days to ship once order is placed*

2.5 Gallon Red Fuel Tank with Voltage Regulator (VR) 2 speed electric pump (Gas, Smoke, Kero or Diesel)

Includes:  18” Fill Line Extension with 30" Return Line and Funnel

NOW cap comes with the No-Spill Cap and Nozzle and can has clear window to see fuel level!!

Features electric pump, fuel probe filler and return line to return the gasoline to fuel tank with no waste or spill. Inline fuel filter traps contaminants before they can be introduced into plane's fuel system! System comes with electric pump and are fully assembled. Can be used for Gas, Smoke, Kero or Diesel.

All Electric Pumps are 12vdc pumps but if run @ 12v's these pumps may pump at too high a pressure. Pumps w/o ESC (Electronic Speed Control) to adjust speed of pump use a 7.2v<9.6v NiMh ~  A123 or LiFe 9.0v or LiPo 7.4v battery. Units w/ESC may use up to a 12vdc pack Battery. Units w/o ESC: may also try different battery voltages to change pump speed!

Options:

• May Add battery and charger: 110vac Pulse Peak Charger, 9.6v/4000mAh NiMh battery + $80
• Electronic Speed Control (ESC) + $60

Note: Electric pumps have XT60 plug that will also accept EC3 female plug

Canister Muffler (Rear Exit) Curved Header 20-30cc Engine
This Canister is easily connected to the DLE 30 or DLE55 engine without adding much extra weight. The canister will significantly reduce the nosie of the engine, and also allow you to keep from having to cut up your cowl as much as with a muffler.

The 30cc Canister Muffler:

This muffler is designed with three levels of filters for the best sound dampening effect and feautures an oil proof converted silicone tube on the end of the muffler. The design makes this muffler very convenient for users to install them on engines.

Secure connection is ensured by the anti-skid joint on the muffler and the included installation clips.

The muffler is made of soft aluminum and is brushed into frosted texture.

Works even better than before at low to medium speeds.

Fast response.

Strong and light weight pipe.

Easy installation.

Includes mufflers, tubes, and clips.

SPECS:
See photos for dimensions
