BG-0731SWP (SAIL WINCH), WATER PROOF, DIGITAL, HV, BRUSHLESS (35.7kg/465.9oz 0.06sec @ 8.4V)

Contact UsCustomer Reviews
  0
  5. BG-0731SWP (SAIL WINCH), WATER PROOF, DIGITAL, HV, BRUSHLESS (35.7kg/465.9oz 0.06sec @ 8.4V)
Tariff Information update
more offers

BG-0731SWP (SAIL WINCH), WATER PROOF, DIGITAL, HV, BRUSHLESS (35.7kg/465.9oz 0.06sec @ 8.4V)

Ask a question about this product
Printable version

Share

Options

Our Price:

$84.99
Quantity (4)

Details

Availability 4 in stock
Weight 0.51 lbs
SKU BBR-BG-0731SWP
Manufacturer Blue Bird

BG-0731SWP (SAIL WINCH), WATER PROOF, DIGITAL, HV, BRUSHLESS (35.7kg/465.9oz 0.06sec @ 8.4V)

Default rotation : 6T (2160°)
Water Proof IP rated: IP=Ingress Protection Rating
6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes

Application
Sail Winch for Larger Boat, Yacht.



Specifications
Torque At 6.0V 25.6 kg-cm / 355.6 oz-in
Torque At 7.4V 31.8 kg-cm / 441.7 oz-in
Torque At 8.4V 35.7 kg-cm / 495.9 oz-in
Speed At 6.0V 0.09 sec / 60°
Speed At 7.4V 0.07 sec / 60°
Speed At 8.4V 0.06 sec / 60°



Power Supply
Operating Voltage Range 4.5V ~ 8.5V ( 4 ~ 6 Cell Ni-MH or 2S Li-Poly & 2S Li-Fe )



Control Specification
Control System Digital Controller
Rotating Direction Clockwise / When Pulse Traveling 900u ~ 2100u second
Operating Travel Total Maximum around 2160° ( 6 Turns / Rotations )



Mechanical Specifications
Ball Bearing Dual ball bearings with 1 piece of oil seal
Gear Durable Steel Alloy Metal Gears
Motor High-Premium Brushless Motor
Horn / Gear Spline 25 Teeth ( Same as F-Type )



Physical Specifications
Dimension (mm) 40.6 x 20.6 x 39.7 mm / 1.6 x 0.81 x 1.56 in
Weight (gram) 72.5 ± 1 grams / 2.55 oz
Product Picture / Dimension Sketch ​





: *
: *
: *
