BLS-A932 SLIM WING, HV MINI, DIGITAL, HIGH TORQUE/SPEED, METAL GEAR, BRUSHLESS

Ask a question about this product

Printable version

Options

Our Price:

$65.00

Quantity (30)

Details


Availability	30 in stock
Weight	0.51 lbs
SKU	BBR-BLS-A932
Manufacturer	Blue Bird

BLS-A932 SLIM WING, HV MINI, DIGITAL, HIGH TORQUE/SPEED, METAL GEAR, BRUSHLESS

Application

Perfect for 3D Airplane, Glider & 1/12th EP On-Road Car

Specifications

Torque At 6.0V	14.2 kg-cm / 197.2 oz-in
Torque At 7.4V	17.5 kg-cm / 243.1 oz-in
Torque At 8.4V	19.8 kg-cm / 275.0 oz-in
Speed At 6.0V	0.10 sec / 60°
Speed At 7.4V	0.08 sec / 60°
Speed At 8.4V	0.07 sec / 60°

Protection Mechanism


Locked Rotor Protection	Stall in 5 sec, output torque goes down.
Temperature Protection	Overheat 85 degrees C (185 degrees F), drive the protection mode and down 75 degrees C (167 degrees F) return to normal mode.

Power Supply

Operating Voltage Range

4.5V ~ 8.7V ( 2S Li-Fe & HV Li-Poly Compatible )

Control Specification

Control System	32-bits CPU Digital Calculator / AD 12-Bits Resolution ( 4096 Steps ) Frequency：Up to 333Hz & Neutral：1500us or 1520us
Dead Band Width	0.001ms ( 1us )

Mechanical Specifications

Ball Bearing	Dual
Gear	All Metal Gears
Motor	High-Efficiency Brushless Motor
Horn / Gear Spline	25 Teeth

Physical Specifications

Dimension (mm)	35.5 x 15 x 29 mm / 1.4 x 0.59 x 1.14 in
Weight (gram)	35.5 ± 1 grams / 1.25 oz
Product Picture / Dimension Sketch
